The 2027 Jayco Jay Feather travel trailer comes in 16 floor plans, from the 23-foot-1-inch 18RBF at $38,243 to the 37-foot 33BH at $58,493. Couples can start with the 24FK, 18RBF or 19MRK, large families with the 27BH, 29BHB, 29QBH or 33BH, and owners of lighter tow vehicles with the four plans rated at 6,995 pounds GVWR or less.
At a glance
- Jayco lists 16 Jay Feather floor plans for the 2027 model year, with starting prices from $38,243 to $58,493 before freight and dealer prep.
- Sleeping capacity runs from up to 2 in the 24FK to up to 11 in the 29QBH, and four other plans sleep up to 8 or 10.
- GVWR ranges from 6,200 pounds on the 18RBF to 9,800 pounds on the new 33BH, so the tow vehicle you need varies widely across the line.
- Jayco's listed cargo carrying capacity stays between 1,405 and 1,760 pounds on every plan, whatever its size.
- Every 2027 Jay Feather has a 55-gallon fresh water tank, a tankless water heater and a 200-watt solar panel in its mandatory packages.
Every specification and price in this guide comes from Jayco's 2027 Jay Feather floor plan index and the 16 individual floor plan pages on jayco.com, read on 20 October 2026. The guide compares the plans on what a shopper can check before visiting a dealer: sleeping capacity, length, weights, cargo capacity, tank sizes and starting price. No trailer was inspected or towed for this guide.
Prices are Jayco's "starting at" MSRPs in US dollars. The build-and-price section of each Jayco floor plan page says the MSRP does not include freight and dealer prep charges. Lengths are Jayco's overall exterior lengths. Jayco also sells the Jay Feather Air, Jay Feather Air SL and Jay Feather SL as separate travel trailer lines with their own floor plans; they are not covered here.
The Jay Feather line runs from a 23-foot plan that sleeps four to a 37-foot plan that sleeps ten, and price generally rises with length.
| 2027 floor plan | Sleeps up to | Overall length | Starting MSRP |
|---|
| 18RBF | 4 | 23 ft 1 in | $38,243 |
| 19MRK | 4 | 23 ft 4 in | $40,403 |
| 21MBH | 6 | 26 ft 8 in | $42,818 |
| 21MML | 3 | 25 ft 5 in | $41,978 |
| 23MBD | 7 | 28 ft | $47,168 |
| 23RK | 6 | 28 ft 7 in | $44,468 |
| 24FK | 2 | 27 ft | $47,243 |
| 25BH | 8 | 29 ft 8 in | $46,493 |
| 25RB | 6 | 30 ft 1 in | $45,623 |
| 26FK | 4 | 33 ft 10 in | $52,628 |
| 27BH | 10 | 32 ft 3 in | $49,745 |
| 27MK | 6 | 33 ft 2 in | $52,350 |
| 29BHB | 10 | 34 ft | $51,068 |
| 29QBH | 11 | 36 ft 1 in | $53,993 |
| 30RKB | 6 | 35 ft 10 in | $53,535 |
| 33BH | 10 | 37 ft | $58,493 |
Price does not always follow size. The 27BH sleeps up to 10 and starts at $49,745, while the 26FK, which sleeps up to 4, starts at $52,628. Jayco shows the 33BH as new for 2027.
Browse travel trailers and other RVs for sale on Searchshop.
Every 2027 Jay Feather weighs between 4,655 and 8,120 pounds unloaded, and Jayco rates them from 6,200 to 9,800 pounds GVWR. GVWR is the most the trailer is rated to weigh when loaded, so it is the number to compare with a tow vehicle's ratings, not the unloaded weight.
| 2027 floor plan | Unloaded weight | Dry hitch weight | GVWR |
|---|
| 18RBF | 4,655 lb | 490 lb | 6,200 lb |
| 19MRK | 4,885 lb | 555 lb | 6,400 lb |
| 21MBH | 5,510 lb | 625 lb | 6,995 lb |
| 21MML | 5,095 lb | 580 lb | 6,500 lb |
| 23MBD | 6,045 lb | 660 lb | 7,500 lb |
| 23RK | 5,765 lb | 665 lb | 7,400 lb |
| 24FK | 5,830 lb | 830 lb | 7,500 lb |
| 25BH | 6,015 lb | 665 lb | 7,600 lb |
| 25RB | 6,130 lb | 715 lb | 7,600 lb |
| 26FK | 7,210 lb | 1,030 lb | 8,700 lb |
| 27BH | 6,725 lb | 860 lb | 8,200 lb |
| 27MK | 7,090 lb | 785 lb | 8,850 lb |
| 29BHB | 7,055 lb | 790 lb | 8,700 lb |
| 29QBH | 7,335 lb | 835 lb | 8,995 lb |
| 30RKB | 7,250 lb | 980 lb | 8,995 lb |
| 33BH | 8,120 lb | 910 lb | 9,800 lb |
Jayco lists unloaded vehicle weight (UVW) and dry hitch weight on each floor plan page. The 26FK carries the heaviest dry hitch weight in the line at 1,030 pounds, followed by the 30RKB at 980 pounds, even though neither is the heaviest trailer. Hitch weight changes as the trailer is loaded, so weigh the loaded trailer before relying on these figures.
Jayco lists a cargo carrying capacity for each floor plan, which equals GVWR minus unloaded weight. That is the room left for water, propane, gear and any options added after the trailer was weighed.
| 2027 floor plan | Cargo capacity | Gray tank | Black tank |
|---|
| 18RBF | 1,545 lb | 38 gal | 38 gal |
| 19MRK | 1,515 lb | 38 gal | 30.5 gal |
| 21MBH | 1,485 lb | 30.5 gal | 30.5 gal |
| 21MML | 1,405 lb | 30.5 gal | 30.5 gal |
| 23MBD | 1,455 lb | 76 gal | 40 gal |
| 23RK | 1,635 lb | 61 gal | 30.5 gal |
| 24FK | 1,670 lb | 76 gal | 38 gal |
| 25BH | 1,585 lb | 76 gal | 38 gal |
| 25RB | 1,470 lb | 61 gal | 38 gal |
| 26FK | 1,490 lb | 90 gal | 30 gal |
| 27BH | 1,475 lb | 76 gal | 38 gal |
| 27MK | 1,760 lb | 70 gal | 30 gal |
| 29BHB | 1,645 lb | 68.5 gal | 30.5 gal |
| 29QBH | 1,660 lb | 60 gal | 30 gal |
| 30RKB | 1,745 lb | 98 gal | 30 gal |
| 33BH | 1,680 lb | 68 gal | 68 gal |
Cargo capacity is closely matched across the line, from 1,405 pounds on the 21MML to 1,760 pounds on the 27MK. Gray tanks vary more, from 30.5 gallons on the 21MBH and 21MML to 98 gallons on the 30RKB. The 33BH is the only plan with a black tank larger than 40 gallons, at 68 gallons. Options installed at the factory or by a dealer count against cargo capacity, so ask for the weight label on the actual trailer.
Five Jay Feather floor plans sleep four or fewer people: the 24FK, 21MML, 18RBF, 19MRK and 26FK. They suit couples and small crews, and they cover almost the whole length range of the line.
- Jay Feather 24FK: sleeps up to 2, 27 ft long, 5,830 lb unloaded, 7,500 lb GVWR, from $47,243. It is the only plan rated to sleep two.
- Jay Feather 21MML: sleeps up to 3, 25 ft 5 in long, 5,095 lb unloaded, 6,500 lb GVWR, from $41,978.
- Jay Feather 18RBF: sleeps up to 4, 23 ft 1 in long, 4,655 lb unloaded, 6,200 lb GVWR, from $38,243. It is the shortest, lightest and lowest-priced Jay Feather.
- Jay Feather 19MRK: sleeps up to 4, 23 ft 4 in long, 4,885 lb unloaded, 6,400 lb GVWR, from $40,403.
- Jay Feather 26FK: sleeps up to 4, 33 ft 10 in long, 7,210 lb unloaded, 8,700 lb GVWR, from $52,628. It has a 90-gallon gray tank and the highest dry hitch weight in the line.
The 18RBF and 19MRK keep length and weight lowest. The 24FK and 26FK are larger trailers for two to four people, and the 26FK starts $14,385 above the 18RBF.
Six Jay Feather floor plans sleep six or seven people: the 21MBH, 23RK, 25RB, 27MK, 30RKB and 23MBD. They span 26 feet 8 inches to 35 feet 10 inches.
- Jay Feather 21MBH: sleeps up to 6, 26 ft 8 in long, 5,510 lb unloaded, 6,995 lb GVWR, from $42,818. It has the lowest GVWR of the six-sleepers.
- Jay Feather 23RK: sleeps up to 6, 28 ft 7 in long, 5,765 lb unloaded, 7,400 lb GVWR, from $44,468.
- Jay Feather 25RB: sleeps up to 6, 30 ft 1 in long, 6,130 lb unloaded, 7,600 lb GVWR, from $45,623.
- Jay Feather 23MBD: sleeps up to 7, 28 ft long, 6,045 lb unloaded, 7,500 lb GVWR, from $47,168. It is the only plan rated to sleep seven.
- Jay Feather 27MK: sleeps up to 6, 33 ft 2 in long, 7,090 lb unloaded, 8,850 lb GVWR, from $52,350. It has the largest cargo capacity in the line, at 1,760 pounds.
- Jay Feather 30RKB: sleeps up to 6, 35 ft 10 in long, 7,250 lb unloaded, 8,995 lb GVWR, from $53,535. It has the largest gray tank in the line, at 98 gallons.
The 21MBH is the choice for six sleepers on a lighter tow vehicle. The 27MK and 30RKB add length and weight; the 27MK has the most cargo capacity and the 30RKB the largest gray tank.
Five Jay Feather floor plans sleep eight or more people: the 25BH, 27BH, 29BHB, 33BH and 29QBH. These are the plans for larger families.
- Jay Feather 25BH: sleeps up to 8, 29 ft 8 in long, 6,015 lb unloaded, 7,600 lb GVWR, from $46,493. It is the shortest and lightest plan in this group.
- Jay Feather 27BH: sleeps up to 10, 32 ft 3 in long, 6,725 lb unloaded, 8,200 lb GVWR, from $49,745.
- Jay Feather 29BHB: sleeps up to 10, 34 ft long, 7,055 lb unloaded, 8,700 lb GVWR, from $51,068.
- Jay Feather 29QBH: sleeps up to 11, 36 ft 1 in long, 7,335 lb unloaded, 8,995 lb GVWR, from $53,993. It has the highest sleeping capacity in the line.
- Jay Feather 33BH: sleeps up to 10, 37 ft long, 8,120 lb unloaded, 9,800 lb GVWR, from $58,493. It is new for 2027 and the longest and heaviest Jay Feather.
The 27BH sleeps up to 10 for $8,748 less than the 33BH, which also sleeps up to 10, and with 1,600 pounds less GVWR. The 29QBH adds one more sleeping place for $4,248 more than the 27BH.
All 16 floor plans share the items below, so the choice comes down mostly to layout, size and weight. Some other features in the mandatory packages are not available on every plan.
- Fresh water and hot water: a 55-gallon fresh water tank and an on-demand 60,000 BTU tankless water heater.
- Mandatory packages: Jayco lists the Customer Value Package and the Jay Sport Package as mandatory. They include a 13,500 BTU ducted roof-mount air conditioner, an 11 cubic foot 12-volt refrigerator and the Overlander I solar package of one 200-watt panel with a 30-amp digital controller.
- Bed: a 60-by-80-inch queen bed, or a 60-by-76-inch bed on Murphy bed models (60 by 80 inches on the 23MBD). Jayco offers a 72-by-80-inch king bed on select models.
- Weather package: Climate Shield, which Jayco describes as zero to 100 degree tested weather insulation.
- Roof: a PVC roofing membrane with a limited lifetime warranty.
The optional Premier Package adds a power five-point stabilization system, dual MaxxAir vent fans and solid-surface kitchen countertops, and is listed at $2,243 on the floor plan pages. Jayco says it reserves the right to change and discontinue models and features without notice, so check the build sheet for the trailer you are buying.
A Jay Feather should be matched to your tow vehicle using the trailer's GVWR and loaded hitch weight, not its unloaded weight. A loaded 29QBH, for example, could weigh up to 8,995 pounds, which is 1,660 pounds more than its 7,335-pound unloaded weight.
- Write down the GVWR and dry hitch weight of the floor plan you want from the tables above.
- Read your tow vehicle's towing rating, payload label and combined weight rating for its exact configuration.
- Remember that hitch weight counts against the vehicle's payload, along with passengers and cargo, and that it changes as the trailer is loaded.
- Ask the dealer for the weight label on the specific trailer, since options add weight.
For the full method, read the Searchshop guide to the best trucks for towing a travel trailer, which covers payload, tongue weight and truck configuration.
The right Jay Feather depends on how many people sleep aboard, how long a trailer your campsites and storage allow, and how much your tow vehicle can handle.
- Couple wanting the smallest trailer: start with the 18RBF or 19MRK.
- Couple wanting more room: compare the 24FK and 26FK.
- Family of up to six on a lighter tow vehicle: the 21MBH.
- Family of eight or more: start with the 25BH or 27BH, then the 29BHB, 29QBH and 33BH if you need more length and capacity.
- Want the most gray tank capacity: look at the 30RKB and 26FK, at 98 and 90 gallons.
Shopping a used Jay Feather? Floor plan codes change over the years, so a code that is not in the tables above may belong to an earlier lineup or to a separate Jay Feather line. Jayco keeps archived pages for earlier model years; read the specifications for that year before comparing it with a 2027 plan.
To compare Jayco with other makers, read Jayco vs Forest River or Grand Design vs Jayco. For another lineup set out the same way, see Grand Design Imagine floor plans, and for general advice on size and inspection, the travel trailer buying guide.
Shop new and used travel trailers on Searchshop and ask each dealer for a written out-the-door price that includes freight and prep.
The Jayco Jay Feather has 16 floor plans for the 2027 model year: the 18RBF, 19MRK, 21MBH, 21MML, 23MBD, 23RK, 24FK, 25BH, 25RB, 26FK, 27BH, 27MK, 29BHB, 29QBH, 30RKB and 33BH. They range from 23 feet 1 inch to 37 feet long. The Jay Feather Air, Air SL and SL are separate lines with their own floor plans.
The 2027 Jay Feather 29QBH sleeps the most, at up to 11 people, according to Jayco. The 27BH, 29BHB and 33BH each sleep up to 10, and the 25BH sleeps up to 8. The 27BH is the lowest-priced of the 10-sleepers at a starting MSRP of $49,745.
A 2027 Jayco Jay Feather starts at $38,243 for the 18RBF and reaches $58,493 for the 33BH, based on Jayco's starting MSRPs. Jayco says its MSRP does not include freight and dealer prep charges. Ask for a written out-the-door figure before comparing offers.
A 2027 Jayco Jay Feather weighs from 4,655 pounds unloaded for the 18RBF to 8,120 pounds for the 33BH. Loaded, the plans are rated from 6,200 to 9,800 pounds GVWR. Use the GVWR and the loaded hitch weight, not the unloaded weight, when checking whether a tow vehicle can handle a particular plan.
