Center console vs dual console comes down to fishing room versus family comfort. A center console puts the helm in the middle of the deck so anglers can work all the way around the boat. A dual console splits the dash into two consoles behind a windshield, giving up some of that walk-around room for bow seating and shelter.
| Factor |
Center console |
Dual console |
| Helm |
One console in the middle of the deck |
Helm console to one side, passenger console to the other |
| Walk-around room |
A walkway on both sides of the console, bow to stern |
A passage between the consoles leads to the bow seating |
| Windshield |
Windshield on the console |
Windshield across the boat in front of both consoles |
| Same-length fuel and livewell (Stingray 17, 22 and 24 ft) |
More fuel and more listed livewell capacity at each length |
Less fuel and less listed livewell capacity at each length |
| Best fit |
Fishing first, family second |
Family days first, fishing second |
The fuel and livewell row comes from Stingray's published specifications, read on 12 October 2026. The rest describes how the two layouts are built.
The two layouts were compared using builders that make both types at the same length, so the hull is not what changes. Stingray builds center console and dual console versions at several lengths, including 17, 22 and 24 feet. Grady-White builds the Fisherman 236 center console and the Freedom 235 dual console on hulls of the same length and beam.
Every specification and price comes from the builder's own website, read on 12 October 2026. Nothing here comes from a test drive or sea trial. Each builder measures weight its own way: Stingray quotes an average dry weight with a named engine, and Grady-White quotes weight without engines. So weights are only compared within one builder, and only where the basis matches.
A center console is built so people can move around the whole boat while fishing. With the helm in the middle, anglers can follow a fish from the bow to the stern on either side of the console.
Builders lean into that layout. The Stingray 22HY (CC) comes with twelve rod holders as standard, and its bow cushions can be removed and rear seats folded to make casting platforms at the bow and stern. Its livewell capacity is listed as 14 plus 17 gallons. The Grady-White Fisherman 236 has a 15.5-gallon livewell and an enclosed head.
Center consoles still carry families. Stingray describes the 22HY (CC) as a boat for "fisherman or family", and Grady-White calls the Fisherman 236 a sportfishing boat and a family-friendly cruiser. The trade-off is that seating and shelter come second to fishing room.
A dual console is built around seating and a windshield, with fishing as a second job. The helm sits on one side and a passenger console on the other, with a windshield across the boat and seating in the bow.
The Stingray 22DC lists a safety glass windshield as standard, describes large bow and aft seating, and has a freshwater sink in its head compartment. It lists a livewell capacity of 11 gallons, with an aerated livewell offered as an option. The Grady-White Freedom 235 has an enclosed head, and Grady-White describes it as ideal for family adventures.
Dual consoles can fish. The 22DC offers an optional fishing package with a fishing seat, and Grady-White describes the Freedom 235 as a versatile dual console for fishing trips and coastal cruising. Dual consoles simply give less room to walk around the boat with a rod.
Browse center console and dual console boats for sale on Searchshop to see both layouts from dealers near you.
At each of the three lengths below, Stingray's dual console carries less fuel and lists less livewell capacity than its center console. Length overall, beam and maximum engine power are the same within each pair.
| Specification |
17-ft pair (17CC / 17DC) |
22-ft pair (22HY CC / 22DC) |
24-ft pair (24HY CC / 24DC) |
| Max engine power |
115 hp / 115 hp |
225 hp / 225 hp |
300 hp / 300 hp |
| Usable fuel |
30 gal / 21 gal |
50 gal / 42 gal |
62 gal / 52 gal |
| Livewell |
12 + 17 gal / 6 gal |
14 + 17 gal / 11 gal |
14 + 17 gal / 11 gal |
| Max capacity |
7 people, 2,000 lb / 7 people, 2,000 lb |
10 people, 3,050 lb / 12 people, 2,900 lb |
12 people, 3,250 lb / 12 people, 3,104 lb |
| Max draft, drive up |
11.5 in. / 11.5 in. |
15.0 in. / 17.0 in. |
16.0 in. / 17.0 in. |
| MSRP |
$44,016 / $38,291 |
$69,696 / $72,647 |
$87,201 / $93,853 |
Lengths overall are 17 ft 3 in., 21 ft 8 in. and 23 ft 8 in. Stingray's model pages link to 2027 model flyers. The pages do not say what the MSRP includes, so ask each dealer for an out-the-door price that lists the engine, trailer, freight and fees.
Weights can be compared for two of the pairs, where Stingray quotes both boats with the same engine. With a 90 hp engine, the 17CC averages 2,100 lb dry and the 17DC 1,900 lb. With a 250 hp engine, the 24HY (CC) and the 24DC both average 3,648 lb dry. The 22-foot pair is quoted with different engines, so its weights are left out.
Grady-White's 23-foot pair shares its length, beam, fuel tank and power limit, so the differences come from the deck layout. The Fisherman 236 and the Freedom 235 both measure 23 ft 7 in. on the center line without swim platforms and engines, with an 8 ft 6 in. beam.
| Specification |
Fisherman 236 (center console) |
Freedom 235 (dual console) |
| Weight without engines |
4,135 lb |
4,420 lb |
| Fuel capacity (standard) |
100 gal |
100 gal |
| Maximum power |
350 hp |
350 hp |
| Transom deadrise |
20 degrees |
20 degrees |
| Hull draft |
18.5 in. |
20 in. |
The Freedom 235 is 285 lb heavier without engines and drafts 1.5 inches more than the Fisherman 236. Grady-White does not publish prices on these model pages.
Choose a center console if fuel and bait capacity matter more than seating. In every Stingray pair above, the center console carries 8 to 10 more gallons of usable fuel and lists more livewell capacity.
That gap does not hold for every builder. Grady-White gives its 23-foot center console and dual console the same 100-gallon standard tank. Compare the specification sheets of the exact models you are considering rather than assuming one layout always carries more.
A dual console gives passengers more protected seats, but not always a higher capacity rating. The windshield runs across the boat in front of both consoles, and the bow is laid out as a seating area.
Capacity ratings vary by model. Stingray rates its 22DC for 12 people and its 22HY (CC) for 10, but the 24-foot pair are both rated for 12 people and the 17-foot pair for 7. The weight limit is lower on both the 22DC and 24DC than on the matching center console. Check the capacity rating of the exact boat, and count gear as well as people against the weight limit.
Neither layout is always cheaper. At Stingray, the 17-foot dual console lists for $5,725 less than its center console, while the 22-foot and 24-foot dual consoles list for $2,951 and $6,652 more.
Those figures are Stingray's published MSRPs read on 12 October 2026, not dealer prices. Asking prices on dealer listings vary with engine, options and dealer, so compare the same engine and options when you set quotes side by side.
Check bridge clearance before you buy if the boat must pass under a low bridge or fit a garage or covered slip. Stingray lists bridge clearance with the standard windshield as 72 inches for the 22HY (CC) and 58 inches for the 22DC. With a T-top or hardtop, before any accessories on the top, the 22HY (CC) is listed at 96 inches.
Those are one builder's figures for one pair. Ask for the clearance of the exact boat and top you are buying.
Pick the layout that matches how most of your days on the water will go.
- Buy a center console if most trips are fishing trips, you want to walk all the way around the boat, or you want the most fuel and livewell capacity a builder offers at your length.
- Buy a dual console if most trips are family days, cruising or watersports with some fishing, and you want a full windshield and bow seating.
- Compare same-length pairs from one builder when you can. The specification sheets show exactly what each layout gives up at your length.
- Check the details that vary by model: capacity rating, fuel, draft, bridge clearance and what the price includes.
For more help choosing, read the center console buying guide, the best boats for fishing and the boat buying guide. Before you sign, use the used boat inspection checklist.
When you know which layout fits, compare boats for sale from dealers on Searchshop and ask each dealer for an out-the-door price.
A dual console boat can fish, but it gives up some fishing room to seating and a windshield. Stingray's 22DC offers an optional fishing package and lists an 11-gallon livewell capacity, and Grady-White describes the Freedom 235 as a versatile dual console for fishing trips and coastal cruising. If most of your trips are fishing trips, a center console gives you more room to move around the boat.
Dual console boats are not always more expensive than center consoles of the same length. At Stingray, the 17DC lists for $5,725 less than the 17CC, while the 22DC and 24DC list for $2,951 and $6,652 more than the matching center consoles. These are Stingray's published MSRPs, read on 12 October 2026.
A dual console does not always carry more people than a center console of the same length. Stingray rates its 22DC for 12 people and its 22HY (CC) for 10, but its 24-foot and 17-foot pairs have the same people rating, and the dual console's weight limit is lower at 22 and 24 feet. Always check the rating on the exact boat.
